Tektronix: The World's Standard in Oscilloscopes

8 out of 10 engineers around the world trust Tektronix to help them debug and test tomorrow's designs faster. With the broadest portfolio of digital oscilloscopes available, the richest set of product features, the most extensive analysis capability and our award-winning service and support, Tektronix has the right oscilloscope to meet your need. Learn more about the different types of oscilloscopes available:



Oscilloscope Selection Guide

From basic signal-checking to high-performance analysis, this selection guide gives an overview of the complete range of oscilloscopes from Tektronix. Comparison tables give high-level specifications and features, and indicate the major differences between each series of oscilloscope. It also includes a matrix showing serial protocols supported by each Tektronix oscilloscope series.

  Oscilloscope Selection Guide




  Oscilloscopes, All, selected button Oscilloscopes, Advanced Signal Analysis, unselected button Oscilloscopes, Sampling, unselected button Oscilloscopes, Mixed Signal & Mixed Domain, unselected button Oscilloscopes, Basic, unselected button Oscilloscopes, Battery Powered & Handheld, unselected button Oscilloscopes, TDS Series, unselected button




Advanced Signal Analysis Oscilloscopes

Make it easy to solve your most difficult challenges

  Image; Bandwidth Digital Channels Sample Rate Record Length DC Vertical Gain Accuracy Automated Measurements

33GHz - 70GHz

-

50GS/s - 200GS/s

62.5M point - 1Gpoint

-

-

DPO70000 / DSA70000 / MSO70000 Digital & Mixed Signal Oscilloscope

4 GHz -  33 GHz

16

(optional)

25 GS/s - 100 GS/s

31.25M point - 1Gpoint

±2%

53

DPO7000 Digital Phosphor Oscilloscope

500 MHz - 3.5 GHz

-

5 GS/s - 40 GS/s

25M point - 500Mpoint

±1%

53

MSO5000 / DPO5000 MIxed Signal Oscilloscope

350 MHz - 2 GHz

16

(optional)

5 GS/s - 10 GS/s

25M point - 125Mpoint

±1.5%

53


Sampling Oscilloscope

Comprehensive support for Electrical and Optical Communication standards

   Image Bandwidth Analog Channels Range
DSA8300 Digital Sampling Oscilloscope DC - 80 GHz

Determined by the sampling modules used, up to8 channels


Mixed Signal and Mixed Domain Oscilloscopes

The most advanced tools for mixed signal debug and design verification

 Image Bandwidth Digital Channels Spectrum Analysis Function Output Generator Sample Rate Record Length
MSO64 up to 8 GHz  up to 32 (optional)   Spectrum View up to instrument bandwidth 1
(optional)
25 GS/s per channel  62.5 or 125 (optional) or 250 (optional) Mpoints
5 Series MSO front 350 MHz
- 2 GHz

Up to 64
(optional)

 Spectrum View up to instrument bandwidth 1
(optional)
6.25 GS/s 62.5 or 125 (optional) Mpoints
MSO5000 / DPO5000 MIxed Signal Oscilloscope 350 MHz
- 2 GHz

16
(optional)

    5 GS/s - 10 GS/s 25 or 125 (optional) Mpoints
4 Series MSO_thumb 200 MHz
- 1.5 GHz

16
(optional)

Spectrum View up to instrument bandwidth
(optional)

1 (optional)  6.25 GS/s 31.25 or 62.5 (optional) Mpoints
MDO4000B 200 MHz
- 1 GHz

16
(optional)

9 kHz -
6 GHz
(optional)

1 (optional)  2.5 or 5 (optional) GS/s 20 Mpoints
MDO3000 Mixed Domain Oscilloscope 100 MHz
- 1 GHz
16 (optional)

1 GHz or
3 GHz
(optional)

1
(optional)
2.5 or 5 (optional) GS/s 10 Mpoints
MDO3000 Mixed Domain Oscilloscope 100 MHz
- 1 GHz
16 (optional)

9 kHz -
3 GHz
(optional)

1
(optional)
2.5 or 5 (optional) GS/s 10 Mpoints
MSO2000B / DPO2000B Mixed Signal Oscilloscope 70 MHz - 200 MHz

16
(optional)



  1 GS/s 1 Mpoints

Basic Oscilloscopes

Performance You Need at a Price You Can Afford

   Image Bandwidth Analog Channels Range Automated Measurements Record Length Sample Rate
TBS2000B TBS2074_1.jpg 70 MHz - 200 MHz 2/4

32

5M point up to 2Gs/s
TBS1000 TBS1000 Digital Storage Oscilloscope 60 MHz - 150 MHz 4

16

2.5k point 1 GS/s

TBS1000B

TBS1000B Oscilloscope 70 MHz - 200 MHz 2

34

2.5k point 1 GS/s - 2 GS/s

TBS1000B-EDU

TBS1000B-EDU Oscilloscope 70 MHz - 200 MHz 2

34

2.5k point 1 GS/s - 2 GS/

Battery Powered Oscilloscopes with Isolated Channels

Safely and easily make 4-channel floating measurements, including 3-phase power measurements

   Image   Float Voltage Range
TPS2000 Digital Storage Oscilloscope

600 VRMS CATII


TDS Series Oscilloscopes


  Image    Bandwidth Analog Channels
TDS2000 Digital Storage Oscilloscope   50 MHz - 200 MHz 2-4

Probes and Accessories



 Probe Type
  • Current Probe
  • Differential Probe - High Voltage
  • Differential Probe - Low Voltage
  • High Voltage Probe - Single-ended
  • Low Voltage Probe - Single-ended
  • Logic Analyzer Probe
  • Optical Probe
  • Passive Probe




Oscilloscope Software

 Basic Oscilloscop

Software Package
Description
AERO Aerospace Serial Triggering and Analysis
AUDIO Audio Serial Triggering and Analysis
AUTO Automotive Serial Triggering and Analysis
AUTOMAX Extended Automotive Serial Triggering and Analysis
COMP Computer serial triggering and analysis
EMBD Embedded serial triggering and analysis
FLEX FlexRay serial triggering and analysis
LMT Limit/Mask test
PWR Power measurement and analysis
USB USB serial triggering and analysis
ENET Ethernet Serial Triggering and Analysis
